Previous Name: Shell Omala Oil

Shell Omala S2 G oils are high quality extreme-pressure oils designed primarily for the lubrication of heavy duty industrial
gears. Their high load carrying capacity and anti-friction characteristics combine to offer superior performance in gears.

Performance Benefits
• Long oil life – Maintenance saving
Shell Omala S2 G oils are formulated to resist thermal and chemical breakdown throughout the maintenance interval. They withstand high thermal loading and resist the
formation of sludge to provide extended oil life capability, even with bulk oil temperatures of up to 100°C in certain applications.
• Excellent wear & corrosion protection
Excellent load carrying capacity reduces gear tooth and bearing wear on both steel and bronze components.
Shell Omala S2 G has excellent corrosion protection, protecting both steel and bronze components, even in the presence of contamination by water and solids.
• Maintaining system efficiency
Shell Omala S2 G oils have excellent water separation properties, such that excess water can be drained easily from lubrication systems to help extend the life of the gears and ensure efficient lubrication of the contact areas.
Water can greatly accelerate surface fatigue of gears and bearings as well as promoting ferrous corrosion on internal surfaces.
Water contamination should therefore be avoided or removed as quickly as possible after the occurrence.

Applications
• Enclosed industrial gear systems
Shell Omala S2 G oils are formulated using an effective sulphur-phosphorus additive system to provide an extreme pressure performance which allow troublefree application in most enclosed industrial gearboxes using steel spur and helical gears.
• Highly loaded gears
Shell Omala S2 G oils have an effective full extreme pressure (EP) additive system allowing them to be used in highly-loaded gear systems.
• Other applications
Shell Omala S2 G oils are suitable for lubrication of bearings and other components in circulating and splash-lubricated systems

For highly-loaded worm drives the Shell Omala “W” series oils arerecommended.

For automotive hypoid gears, the appropriate Shell Spirax Oil should be used.

Specifications and Approvals
Meets ISO 12925-1 Type CKD, except ISO 680-1000. ISO 680 meets CKC.
Meets DIN 51517- Part 3 (CLP), except ISO 1000
Meets AGMA 9005- EO2 (EP)

Meets US Steel 224
Meets David Brown S1.53.101,102,103,104
Meets MAG (Cincinatti Machine)
P34,35,59,63, 74, 76-78
